DN(mm）Nominl DiameterD1D2n-ΦLTtMpa Working pressurePVDF20751054-1441401550.725851154-1441601660.732
DN(mm）Nominl Diameter | D1 | D2 | n-Φ | L | T | t | Mpa Working pressure | |
PVDF | ||||||||
20 | 75 | 105 | 4-14 | 4 | 140 | 15 | 5 | 0.7 |
25 | 85 | 115 | 4-14 | 4 | 160 | 16 | 6 | 0.7 |
32 |
|
| 4-18 |
|
|
|
|
|
40 | 110 | 150 | 4-18 | 4 | 180 | 18 | 8 | 0.7 |
50 | 125 | 165 | 4-18 | 4 | 200 | 21 | 8 | 0.7 |
65 | 145 | 185 | 4-18 | 4 | 240 | 23 | 9 | 0.7 |
80 | 160 | 200 | 8-18 | 4 | 260 | 25 | 9 | 0.7 |
100 | 180 | 220 | 8-18 | 4 | 300 | 26 | 10 | 0.5 |
125 | 210 | 250 | 8-18 | 4 | 350 | 27 | 14 | 0.5 |
150 | 240 | 280 | 8-23 | 4 | 400 | 27 | 16 | 0.5 |
200 | 295 | 340 | 8-23 | 4 | 500 | 34 | 18 | 0.5 |
